LMSTS-300 Stickpack & Sachet Packing Machine – LENIS

LMSTS-300 is a small and economic VFFS bagging machine that makes, fills, and seals pouches in one automatic process. These machines are suitable for powders, liquids and grains.

Bag Types

These single-lane stickpack packing machines can produce back-sealed stickpacks and 3-side and 4-side sealed sachets.

Filler Options

  1. Auger Filler (for powder products)
  2. Volumetric Cup Filler (for grains)
  3. Tablet Counting Filler (for tablets)
  4. Piston Pump Filler (for liquid products)

Optional Equipment

  1. Possibility of machine integration with ERP system. (SAP, Microsoft Dynamics, and other ERP software)
  2. SCADA integration
  3. Screw elevator/conveyor for automatic continuous feeding of powder products
  4. Z-bucket elevator for automatic continuous feeding of granular products
  5. Agitator/mixer for liquid or paste products
  6. Product counter and stacking belt conveyor
  7. Extra filler equipment for different powder, granular, liquid or part type products packaging in a single machine. The choices are: volumetric cup filler, multi-head weigher, piston pump filler, auger filler, tablet counting filler, and vibrating filler
  8. Air compressor
  9. Complete production line including Metal Detector, Boxing Machines, Wrapping Machines, etc.

Models
Technical Specifications
Bag Types & Shapes
Drawings
Brochure
Models
Technical Specifications

LMSTS-300P for Powder Packing
LMSTS-300L for Liquid Packing
LMSTS-300G for Grain Packing
LMSTS-300P for Powder Packing

LENIS LMSTS-300P Single-Lane Stickpack Packing Machines for Powder Packing
ParameterDescription
Build MaterialSUS304 Food Grade Stainless Steel (Option: SS316)
Measuring TechnologyAuger Screw Filler
Bag TypeBack Sealed Stickpack, 3-Side & 4-Side Sealed Sachets
Filling Range0 ~ 50 ml
Bag Length50 ~ 150 mm
Bag Width30 ~ 120 mm
Maximum Packing Speed25 ~ 40 bags/min
Filling Accuracy1.0 %
Supply Voltage220V, 1ph, 60Hz or Custom
Power Consumption1.5 kW
Additional Function 1Color Code Detection Function
Additional Function 2Date Code Printer, 1 ~ 3 Lines of Code
CertificationCE, ISO and CSA (Optional)

LMSTS-300L for Liquid Packing

LENIS LMSTS-300L Single-Lane Stickpack Packing Machines for Liquid Packing
ParameterDescription
Build MaterialSUS304 Food Grade Stainless Steel (Option: SS316)
Measuring TechnologyPiston Pump Filler
Bag TypeBack Sealed Stickpack, 3-Side & 4-Side Sealed Sachets
Filling Range0 ~ 50 ml
Bag Length50 ~ 150 mm
Bag Width30 ~ 120 mm
Maximum Packing Speed25 ~ 40 bags/min
Filling Accuracy1.0 %
Supply Voltage220V, 1ph, 60Hz or Custom
Power Consumption1.5 kW
Additional Function 1Color Code Detection Function
Additional Function 2Date Code Printer, 1 ~ 3 Lines of Code
CertificationCE, ISO and CSA (Optional)

LMSTS-300G for Grain Packing

LENIS LMSTS-300G Single-Lane Stickpack or Sachet Packing Machines for Grain Packing
ParameterDescription
Build MaterialSUS304 Food Grade Stainless Steel (Option: SS316)
Measuring TechnologyVolumetric Cup Filler
Bag TypeBack Sealed Stickpack, 3-Side & 4-Side Sealed Sachets
Filling Range0 ~ 50 ml
Bag Length50 ~ 150 mm
Bag Width30 ~ 120 mm
Maximum Packing Speed25 ~ 40 bags/min
Filling Accuracy1.0 %
Supply Voltage220V, 1ph, 60Hz or Custom
Power Consumption1.5 kW
Additional Function 1Color Code Detection Function
Additional Function 2Date Code Printer, 1 ~ 3 Lines of Code
CertificationCE, ISO and CSA (Optional)

Bag Types & Shapes

lenis-stickpack-sachet-packing-vffs-machineslenis-stick-pack-sachet-packing-vffs-machineslenis-stickpack-sachet-packing-vffs-machines-styles

Drawings

LMSTS-300P for Powder Packing
LMSTS-300L for Liquid Packing
LMSTS-300G for Grain Packing
LMSTS-300P for Powder Packing

lenis-stickpak-packaging-machine-LMSTS-300-drawing

LMSTS-300L for Liquid Packing

lenis-stick-pack-sachet-liquid-packing-vffs-machines

LMSTS-300G for Grain Packing

lenis-stick-pack-sachet-grain-packing-vffs-machines

Brochure

LMSTS-300P for Powder Packing
LMSTS-300L for Liquid Packing
LMSTS-300G for Grain Packing
LMSTS-300P for Powder Packing
LMSTS-300L for Liquid Packing
LMSTS-300G for Grain Packing

Warranty

All parts are under One-Year Warranty for defects from the manufacturer. Any other defect caused by human error, mishandling, wear-and-tear & any foreseeable conditions will not be covered by this warranty. All electronic parts and component can be guaranteed by original part’s manufacturer or LENIS.

Service & Support

LENIS offers three tiers of service & support to its customers as follows:

  1. Online Troubleshooting
  2. Through Servicing & Maintenance Partners Near You
  3. Direct In-Person Troubleshooting from Our Main Servicing & Maintenance Team

Our aim and vision are to provide sales and service around the world. LENIS offers competitive pricing of the provided solutions through an online marketing strategy to keep the prices of the solution competitive and collaborate with servicing and maintenance partners all over North America and around the world to offer the best services to the valued customers. We are committed to providing online troubleshooting of the machines in the first place and also provide maintenance service through our partners near you.

LENIS machines use standard components and we avoid proprietary components as much as possible to ensure that servicing and maintenance of the machine become simple and easy. Because of the simplicity and openness of our designs, our partners near you will be able to assist you at the time when online troubleshooting becomes ineffective. In extreme cases, our main servicing and maintenance team can visit your machines in-person.
